| Model | KKE-430 | KKE-530 | KKE-440 | KKE-540 | KKE-550 |
|---|---|---|---|---|---|
| Core Box Size (L x H x W) |
450 x 300 x 150mm | 500 x 300 x 200mm | 450 x 400 x 250mm | 500 x 400 x 300mm | 550 x 400 x 350mm |
| Max. Core Size (L x H x W) |
370 x 280 x 100mm | 420 x 280 x 150mm | 370 x 380 x 200mm | 420 x 380 x 250mm | 470 x 380 x 300mm |
| Operation Mode | Manual/Single Cycle/Auto Cycle | ||||
| Production Speed | 40 ~ 70 seconds/cycle, depends on size and shape of products | ||||
| Heating Type | LPG or Electrical | ||||
| Max. Blowing Capacity | 10 kgs | 10-15 kgs | 15-20 kgs | 15-25 kgs | 15-25 kgs |
| Sand Storage Capacity | 200 ~300 kgs | ||||
| Operation Pressure | 5-6 kgs/cm² | ||||
| Sand Blowing Pressure | 1-4 kgs/cm² | ||||
| Weight | 2500 kgs | 2800 kgs | 3000 kgs | 3200 kgs | 3500 kgs |
| Dimension | 2560 x 2500 x 3500 mm | 2650 x 2500 x 3550 mm | 2860 x 2500 x 3600 mm | 3100 x 2500 x 3650 mm | 3500 x 2500 x 3700 mm |
